Antenna 9dBi +MAGE BASE + RP SMA MALE + RG174 L=3000mm


Applications:
  • 1.71GHz-2.17GHz 09dBi ISM Band
  • DCS1800 GSM1800 1.8GHz 2G
  • PCS1900 GSM1900 1.9GHz
  • PCS2000 GSM2000 3G 3.5G
  • WiFi, CDMA, RFID, GSM
  • Directional and multipoint applications
  • Public Wireless Hotspot
  • Wireless Video Systems

Features :
  • Superior performance
  • Light weight
  • Easy set up
  • 3m cable
  • Mage Base
  • 360 degree OMNI directional
  • RoHS Compliant

A9BM-10013R174-A3000

SPECIFICATIONS:
Applications:
Frequency Range 1.71~2.17GHz
V.S.W.R ≤1.5
Return Loss ≥-14db
Antenna Type Collinear
Gain 9dBi
Polarization Vertical
Maximum Power 50W
Vertical Beam-with 12°
Horizontal Beam-with 360°
Impedance 50Ω
Connector RP SMA Male
Mechanical Specifications:
Length

413.6mm
Diameter 12mm
Weight 93g
Wind Survival N/A
Radome Material Black ABS
Operating Temperature -40℃ to +80℃
Clamps N/A
Mounting N/A
RoHS Compliant YES
