| 2.3~2.4GHz Mini OMNI Antenna with Gain 11dBi for N FEMALE |
| |
 |
| |
| Applications: |
- 2.3GHz-2.4GHz 11dBi ISM Band
- IEEE 802.11X Wireless LAN
- Directional and multipoint applications
- Public Wireless Hotspot
- WiMAX, WiBro
- Wireless Video Systems
|
|
| Features : |
- Superior Performance
- The Weight is light
- Good appearance designs
- Installed for vertical or horizontal polarization
- Outdoor antenna for public Hot spots
- Heavy Duty mounting
- RoHS Compliant
|
|
| |
 |
MOA-2324-11N-F |
|
| |
| SPECIFICATIONS: |
| Applications: |
| Frequency Range |
2.3~2.4GHz |
| V.S.W.R |
≤1.5:1 |
| Return Loss |
≥-14db |
| Antenna Type |
Collinear |
| Gain |
11dBi |
| Polarization |
Vertical |
| Maximum Power |
50W |
| Vertical Beam-with |
9° |
| Horizontal Beam-with |
360° |
| Impedance |
50Ω |
| Connector |
N-Female |
|
|
|
| Mechanical Specifications: |
Length
|
940mm |
| Diameter |
18.8mm |
| Weight |
165g |
| Wind Survival |
>120 MPH |
| Radome Material |
White Fiberglass |
| Operating Temperature |
－40℃ to ＋80℃ |
| Clamps |
Cable Tie |
| Mounting |
Multiple options |
| RoHS Compliant |
YES |
|
|
|
| |
 |
| |
|
|
