PANEL Antenna II 2.3~2.5GHz 20dBi for N FEMALE


Applications:
  • 2.3GHz-2.5GHz 18dBi ISM Band
  • IEEE 802.11X Wireless LAN
  • Directional and multipoint applications
  • Public Wireless Hotspot
  • WiMAX, WiBro
  • Wireless Video Systems


Features :
  • Superior Performance
  • The Weight is light
  • Good appearance designs
  • Optional Mounting Kits available
  • Installed for vertical or horizontal polarization
  • Heavy Duty mounting
  • RoHS Compliant

PAII-2325-20N-F

SPECIFICATIONS:
Applications:
Frequency Range 2.3~2.5GHz
V.S.W.R ≤1.5
Return Loss ≥-14db
Antenna Type PCB patch
Gain 20.5dBi
Polarization Vertical or Horizontal
Maximum Power 50W
Vertical Beam-with 16°
Horizontal Beam-with 15°
Impedance 50Ω
Connector N-Female
Mechanical Specifications:
Size

L351 x W396 x H35mm
Weight 2300g
Wind Survival N/A
Wind Survival >150 MPH
Radome Material ASA + UV resistance
Operating Temperature -40℃ to +80℃
Clamps Cable Tie
Mounting 20-30mm
RoHS Compliant YES
