You Are Here: Home > 2.3GHz-2.4GHz Antenna > Directional Panel WLAN Antenna |
|
Taiwan Wireless antenna/wifi Antenna/Antenna2.4ghz 5.8ghz Dual Band DVB-T Wlan Antenna/RFconnector/Cable Asseccblies/Antenna Accessoriess
PANEL Antenna II 2.3~2.7GHz 14dBi
for N FEMALE |
|
|
|
Applications: |
- 2.3-2.7 GHz Applications
- IEEE 802.11b, 802.11g, 802.11n Wireless LAN Applications
- 802.16WiMax Networks
- Directional and multipoint applications
- Public Wireless Hotspot
- Wi-Fi WiMAX RFID
- Wireless Video Systems
|
|
Features : |
- Superior Performance
- The Weight is light
- Good appearance designs
- DC Short lightning protection
- Installed for vertical or horizontal polarization
- Outdoor antenna for public Hot spots
- Heavy Duty mounting
- RoHS Compliant
|
|
|
|
|
SPECIFICATIONS: |
Applications: |
Frequency Range |
2.3~2.7GHz |
V.S.W.R |
≤1.5 |
Return Loss |
≥-14db |
Antenna Type |
PCB patch |
Gain |
14dBi |
Polarization |
Vertical or Horizontal |
Maximum Power |
50W |
Vertical Beam-with |
30° |
Horizontal Beam-with |
30° |
Impedance |
50Ω |
Connector |
N-Female |
|
|
|
Mechanical Specifications: |
Size
|
L239 x W239 x H30mm |
Weight |
774.5g |
Wind Survival |
N/A |
Wind Survival |
>150 MPH |
Radome Material |
ASA + UV resistance |
Operating Temperature |
-40℃ to +80℃ |
Clamps |
U-bolt |
Mounting |
86-126mm |
RoHS Compliant |
YES |
|
|
|
|
|
|
|
|
