2.4GHz-2.5GHz Antenna
> Omnidirectional WLAN Antenna |
| |
Taiwan Wireless antenna/wifi Antenna/Antenna2.4ghz 5.8ghz Dual Band DVB-T Wlan Antenna/RFconnector/Cable Asseccblies/Antenna Accessoriess
| 2.4GHz OMNI Antenna with Gain 12dBi |
| |
 |
| |
| Applications: |
- 2.4GHz-2.5GHz 12dBi ISM Band
- IEEE 802.11b,802.11g,802.11b/g,802.11n Wireless Lan
- Omni Directional Multipoint applications
- Bluetooth ,Point to Multipoint
- Pubic Wireless Hotspot
- WiFi,RFID
- Wireless Video Systems
|
|
| Features : |
- Superior Performance
- The Weight is light
- Good appearance designs
- Installed for Collinear Vertical Polarization
- Behind and support is an aluminum
- Outdoor antenna for public Hot spots
- RoHS Compliant
|
|
| |
 |
OA-2450-12 |
|
| |
| SPECIFICATIONS: |
| Applications: |
| Frequency Range |
2.4~2.483GHz |
| V.S.W.R |
≤1.5:1 |
| Return Loss |
≥-14db |
| Antenna Type |
Collinear |
| Gain |
12dBi |
| Polarization |
Vertical |
| Maximum Power |
50W |
| Vertical Beam-with |
7° |
| Horizontal Beam-with |
360° |
| Impedance |
50Ω |
| Connector |
N-Female |
|
|
|
| Mechanical Specifications: |
Length
|
1420mm |
| Diameter |
35mm |
| Weight |
850g |
| Wind Survival |
>150 MPH |
| Radome Material |
White Fiberglass |
| Operating Temperature |
－40℃ to ＋80℃ |
| Clamps |
U-bolt |
| Mounting |
94 – 120mm |
| RoHS Compliant |
YES |
|
|
|
| |
| |
 |
| |
|
|
