2.4GHz-2.5GHz Antenna
> Directional Panel WLAN Antenna |
| |
Taiwan Wireless antenna/wifi Antenna/Antenna2.4ghz 5.8ghz Dual Band DVB-T Wlan Antenna/RFconnector/Cable Asseccblies/Antenna Accessoriess
| 2.4GHz PANEL Antenna 20dBi |
| |
 |
| |
| Applications: |
- 2.4GHz-2.5GHz 20dBi ISM Band
- IEEE 802.11b, 802.11g, 802.11n Wireless LAN
- Directional and multipoint applications
- Bluetooth、WiFi, RFID
- Public Wireless Hotspot
- Wireless Video Systems
|
|
| Features : |
- Superior Performance
- The Weight is light
- Good appearance designs
- Outdoor antenna for public Hot spots
- Heavy Duty mounting
- RoHS Compliant
|
|
| |
 |
PA-2450-20 |
|
| |
| SPECIFICATIONS: |
| Applications: |
| Frequency Range |
2.4~2.483GHz |
| V.S.W.R |
≤1.5 |
| Return Loss |
≥-14db |
| Antenna Type |
PCB patch |
| Gain |
20dBi |
| Polarization |
Vertical or Horizontal |
| Maximum Power |
50W |
| Vertical Beam-with |
16° |
| Horizontal Beam-with |
15° |
| Impedance |
50Ω |
| Connector |
N-Female |
|
|
|
| Mechanical Specifications: |
Size
|
L351 x W396 x H35mm |
| Weight |
2300g |
| Wind Survival |
> 150 MPH |
| Radome Material |
ABS + UV resistance |
| Operating Temperature |
－40℃ to ＋80℃ |
| Clamps |
U-bolt |
| Mounting |
86-126mm |
| RoHS Compliant |
YES |
|
|
|
| |
 |
| |
|
|
