5.3GHz PANEL II Antenna 18dBi for N FEMALE


Applications:
  • 5.2GHz-5.3GHz 18dBi ISM Band
  • IEEE 802.11a , 802.16 Networks
  • Directional and multipoint applications
  • WiMax, CDMA
  • Wireless Video Systems
  • Frequency Ultra-wide
  • Wireless Lan Systems

Features :
  • Superior performance
  • The weight is light
  • Good appearance designs
  • Optional Mounting Kits available
  • Installed for vertical or horizontal polarization
  • Outdoor antenna for public hot-spots
  • Heavy Duty monuting
  • RoHS Compliant

PAII-5300-18N-F

SPECIFICATIONS:
Applications:
Frequency Range 5.2~5.3GHz
V.S.W.R ≤1.5
Return Loss ≥-14db
Antenna Type PCB patch
Gain 18dBi
Polarization Vertical or Horizontal
Maximum Power 50W
Vertical Beam-with 22°
Horizontal Beam-with 20°
Impedance 50Ω
Connector N-Female
Mechanical Specifications:
Size

L240 x W240 x H35mm
Weight 774.5g
Wind Survival > 150 MPH
Radome Material ABS + UV resistance
Operating Temperature -40℃ to +80℃
Clamps Multiple options
Mounting Multiple options
RoHS Compliant YES
