| 5.5GHz OMNI Antenna with Gain 10dBi |
| |
 |
| |
| Applications: |
- 5.4GHz-5.6GHz 10dBi ISM Band
- IEEE 802.11a Applications
- Omni Directional and multipoint applications
- WiFi
- Public Wireless Hotspot
- Wireless Video Systems
|
|
| Features : |
- Superior Performance
- The Weight is light
- Good appearance designs
- Installed for vertical or horizontal polarization
- Outdoor antenna for public Hot spots
- Heavy Duty mounting
- RoHS Compliant
|
|
| |
 |
OA-5500-10 |
|
| |
| SPECIFICATIONS: |
| Applications: |
| Frequency Range |
5.4~5.6GHz |
| V.S.W.R |
≤1.5:1 |
| Return Loss |
≥-14db |
| Antenna Type |
Collinear |
| Gain |
10dBi |
| Polarization |
Vertical |
| Maximum Power |
50W |
| Vertical Beam-with |
10° |
| Horizontal Beam-with |
360° |
| Impedance |
50Ω |
| Connector |
N-Female |
|
|
|
| Mechanical Specifications: |
Length
|
670mm |
| Diameter |
35mm |
| Weight |
620g |
| Wind Survival |
>150 MPH |
| Radome Material |
Black Fiberglass |
| Operating Temperature |
－40℃ to ＋80℃ |
| Clamps |
U-bolt |
| Mounting |
32-45mm |
| RoHS Compliant |
YES |
|
|
|
| |
 |
| |
|
|
