| 802.11a/b/g/n High Power USB Adapter |
| |
 Driver Download Area |
| |
| 802.11b/g/n 33dBm WLAN USB ADAPTER |
| |
 |
| |
 |
USB-2450-33-3 |
|
| |
| SPECIFICATIONS: |
Standard
|
IEEE 802.11b/g/n |
| Frequency Range |
2412MHz - 2484MHz |
| Access Protocol |
CSMA/CA |
| Date Rate |
802.11g: 54, 48, 36, 24, 18, 12, 9 & 6Mbps |
| 802.11b: 11, 5.5, 2 and 1 Mbps with auto-rate fall back |
| 802.11n: 135, 65 Mbps |
| Security |
64/128bit WEP |
| WPA(TKIP with IEEE 802.1x) |
| WPA2(AES with IEEE 802.1x) |
| Number of operation channel |
2.412~2.462GHz(Canada, FCC) / 11Channels |
| 2.412~2.484GHz(Japan, TELEC) / 14 Channels |
| 2.412~2.472GHz(Euro, ETSI) / 13 Channels |
| RF Output Power(Typical) |
20~33dBm (100mw~2000mw) with Antenna |
| Sensitivity |
54Mpbs (64QAM): -76dbm |
| 11 Mbps (CCK): -91dBm |
| 65Mbps: -76dBm± 2dB |
| 135Mbps :-74dBm± 2dB |
| Operation Voltage |
5V |
| Operating Temperature |
-10 ~ 65 Celsius |
| Storage Temperature |
-10 ~ 65 Celsius |
| Humidity |
5 ~98% (non-condensing) |
| Operating System |
Windows98SE, ME, 2000, XP, SP2, Vista, MAC, Linux |
| Interface |
mini USB |
| Size |
L72 x W36 x H13 mm |
| Weight |
70g |
| Verification of compliance |
RoHS |
|
|
|
| |
|
|
