| Specification |
| Model |
USB-2450-33-03 |
| Standard |
IEEE 802.11b/g/n |
| RF Output Power(Typical) |
20~33dBm (100mw~2000mw) with Antenna |
| Frequency Range |
2412MHz - 2484MHz |
| Number of operation channel |
2.412 - 2.462GHz (Canada, FCC) / 11 Channels |
| 2.412 - 2.484GHz (Japan, TELEC) / 14 Channels |
| 2.412 - 2.472GHz (Euro, ETSI) / 13 Channels |
| Security |
64/128bit WEP |
| WPA(TKIP with IEEE 802.1x) |
| WPA2(AES with IEEE 802.1x) |
| Access Protocol |
CSMA/CA |
| Data Rate |
11g: 54, 48, 36, 24, 18, 12, 9& 6Mbps |
| 11b: 11, 5.5, 2 and 1 Mbps with auto-rate fall back |
| 11n: 135, 65 Mbps |
| Sensitivity: |
54Mpbs (64QAM): -76dbm |
| 11 Mbps (CCK): -91dBm |
| 65Mbps: -76dBm± 2dB |
| 135Mbps :-74dBm± 2dB |
| Operation Temperature |
Storage -10°C ~ +65°C |
| Storage Temperature |
-10~65℃ ambient temperature |
| Storage Humidity |
5%~98% non-condensing |
| Driver support |
Windows 2000, XP 32/64, Vista 32/64, 7 32/64
Linux Mac Support S/W AP |
| Operation Voltage |
5V |
| Interface |
mini USB |
| Size |
L72 x W36 x H13 mm |
| Weight |
70g |
| Verification of compliance |
RoHS |
