| Specification |
| Model |
usb-2450-25 |
| Standard: |
IEEE 802.11b, IEEE 802.11g (WiFi Compatible) |
| Chipset: |
Realtek 8187L + 8225 |
| Frequency Band: |
2.412GHz ~ 2.484GHz unlicensed ISM band |
| Data Rate: |
IEEE 802.11b: 1, 2, 5.5, 11Mbps |
| IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps |
| Transmitter Power: |
11g : 15 ± 2dBm@54Mbps, EVM<-24dB |
| 11b : 25 ± 2dBm, EVM <35% |
| Receive Sensitivity: |
Operating at 11Mbps:<-82dBm@8%PER, |
| 54Mbps:<-65dBm@10%PER |
| Operating Range: |
Up to 1000M, depending on surrounding environment |
| Power Consumption: |
Transmit:<600mA ; Receive:<400mA |
| Antenna |
attached dipole Antenna |
| Security: |
WEP (64/128/256bit), WPA, WPA-PSK, WPA2 TKIP/AES, WPA2-PSK |
| I/O Interface: |
USB2.0/1.1 |
| Operating System: |
Windows98SE, ME, 2000, XP, SP2, Vista, MAC, Linux |
| Operating Temperature: |
-10 ~ 55 Celsius |
| Storage Temperature: |
-20 ~ 70 Celsius |
| Humidity: |
10 ~90% (non-condensing) |
| Size: |
Palm: 6.5 (L)x4.0 (W)x1.5 (H)cm ;
BOX: 15(L)x16(W)x3.8(H)cm |
| Weight: |
palm: 37.8g (Color BOX: 200g) |
| Warranty |
1 year |
|
 |
 |
 |
 |
|
