| Specification |
| Model |
USB-2450-23 |
| Standard: |
IEEE 802.11b/g |
| Chipset: |
RTL8187B |
| Frequency Band: |
2.412GHz ~ 2.484GHz unlicensed ISM band |
| Data Rate: |
IEEE 802.11b: 1, 2, 5.5, 11 Mbps |
| IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Transmitter Power: |
22dBm ± 1dBm
(High-powered for better reception and transmission) |
| Receive Sensitivity: |
Operating at 11Mbps: <-82dBm@8%PER, |
| 54Mbps: <-70dBm@8%PER |
| Power Consumption: |
Transmit: <500mA, Receive: <270mA |
| Security: |
WEP (64/128bit or 256-bit), WPA-PSK, WPA2-PSK |
| I/O Interface: |
USB2.0/1.1 |
| Operating System: |
Windows98SE, ME, 2000, XP, SP2, Vista, MAC, Linux |
| Operating Temperature: |
0 ~ 55 Celsius |
| Storage Temperature: |
-20 ~ 70 Celsius |
| Humidity: |
5 ~ 90% (non-condensing) |
| Connection: |
RP SMA female |
| Approval: |
CE, FCC |
|
 |
 |
 |
 |
|
